Military
Emission measurements and immunity tests
DARE!! Consultancy is equiped to carry out tests under MIL standard 461 C, D and E. Specific US Defense related information can be found on the Nardic Publications and Regulations site.
Emission measurements are performed from 10 kHz to 40 GHz. Immunity testing is performed in the band of 10 kHz to 40 GHz at levels up to 300 V/m. Military Standard 461E specifies a number of emission and immunity requirements.
Requirements:
|
Requirement |
Description |
|
CE101 |
Conducted emissions, Power Leads, 30 Hz to 10 kHz |
|
CE102 * |
Conducted emissions, Power Leads, 10 kHz to 10 MHz |
|
CE106 |
Conducted emissions, Antenna Terminal, 10 kHz to 40 GHz |
|
CS101 |
Conducted Susceptibility, Power leads, 30 Hz to 150 kHz |
|
CS103 |
Conducted Susceptibility, Antenna Port, Intermodulation, 15 kHz to 10 GHz |
|
CS104 |
Conducted Susceptibility, Antenna Port, Rejection of Undesired Signals, 30 Hz to 20 GHz |
|
CS105 |
Conducted Susceptibility, Antenna Port, Cross-Modulation, 30 Hz to 20 GHz |
|
CS109 |
Conducted Susceptibility, Structure Current, 60 Hz to 100 kHz |
|
CS114 * |
Conducted Susceptibility, Bulk Cable Injection, 10 kHz to 200 MHz |
|
CS115 |
Conducted Susceptibility, Bulk Cable Injection, Impulse Excitation |
|
CS116 |
Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads, 10 kHz to 100 MHz |
|
RE101 |
Radiated Emissions, Magnetic Field, 30 Hz to 100 kHz |
|
RE102 * |
Radiated Emissions, Electric Field, 10 kHz to 18 GHz |
|
RE103 |
Radiated Emissions, Antenna Spurious and Harmonic Outputs, 10 kHz to 40 GHz |
|
RS101 |
Radiated Susceptibility, Magnetic Field, 30 Hz to 100 kHz |
|
RS103 * |
Radiated Susceptibility, Electric Field, 2 MHz to 40 GHz |
|
RS105 |
Radiated Susceptibility, Transient Electromagnetic Field |
You can also call or email us. Please see the contact information above.
